S S Welded Grid Wall Panel
The main material of Stainless steel welded Grid Wall Panel are used to displaying handcrafts on supermarket. Its easy to hang them from a pop-up canopy rail and then hang items on them with small or large hooks.As long as you have space to transport them, they are super handy and look professional, gridwall panels. These are in perfect condition, feel nice and solid/sturdy just like the other set, and will work perfectly for bringing to shows and displaying my art.it is top notch.
Common stainless Steel Wire Raw Materials include:
Stainless Steel Wire 304
Stainless Steel Wire 304L
Stainless Steel Wire 316
Stainless Steel Wire 316L
Mild steel wire .
Characteristics:
Stainless steel welded Grid Wall Panel offer excellent characteristics such as corrosion resistance, oxidation resistance, acid resistance, alkali resistance, aging resistance, sunshine resistance and weather resistance.
Besides this kind of product has flat even surface and strong structure, therefore this product has a long service life. Good material life of up to several decades.
Specification of Stainless steel welded mesh Guards | ||||
Item | Mesh Size | Wire Diameter | Panel Width & Length | |
SSWMPS-01 | 12.7 mm | 1/2" × 1/2" | 1.0–2.0 mm | 3 feet × 6 feet |
SSWMPS-02 | 25.4 mm | 1" × 1" | 1.5–3.5 mm | |
SSWMPS-03 | 38.1 mm | 1-1/2" × 1-1/2" | 2.0–5.0 mm | |
SSWMPS-04 | 50.8 mm | 2" × 2" | 2.0–6.0 mm | |
SSWMPS-05 | 76.2 mm | 3" × 3" | 3.0–7.0 mm | |
SSWMPS-06 | 101.6 mm | 4" × 4" | 3.0–8.0 mm | |
SSWMPS-07 | 127 mm | 5" × 5" | 4.0–9.0 mm | |
SSWMPS-08 | 152.4 mm | 6" × 6" | 4.0–10.0 mm | |
other panel sizes can also be made according to request | ||||
The most popular products and specifications：
4' × 8' panels in stainless steel with 4" opening and 4.0 mm wire diameter.
4" × 4" openings mesh panel. Ideally 3' × 16' or similar that can be cut down to size.
Stainless steel mesh 50 mm × 50 mm, wire diameter 4 mm.
304 stainless steel welded mesh panel with 2" × 2" mesh size that is 5 ft. by 10 ft.
Stainless steel panels, approx 72 × 60, 1/2 ' squares for building an aviary.
Stainless steel 4" × 4" wire panel. 4 or 6 gauge 10' long by 30" tall or 5' tall.
Stainless steel welded mesh panel (4 ft. × 8 ft. and 5 ft. × 10 ft.) from 16 or 14 gauge wire 1 × 1/2" for outdoor aviary.
51" × 43" × 1-1/2" sq. × 4 mm thick stainless steel weld mesh.
Stainless steel wire mesh black coated finish 12 mm × 12 mm square mesh.
Stainless steel wire mesh screen 4 mm × 4 mm square black coated.
304 Stainless steel and 316 Stainless steel 10' by 10' sections with 2" × 2" openings with the 2 mm diameter used in light weight application.
4 ft. long × 3 ft. wide of the 1/2" × 1/2" stainless steel 304 mesh piece, bordering these pieces with 2" × 2" ninety degree angle 304 stainless steel.
10 gauge and 8 gauge 2" × 2" stainless steel heavy duty welded mesh guarding bar for bridge building.
Stainless steel welded mesh panel, 1" × 1", 1-1/2" × 1-1/2", 2" × 2" mesh, 3 mm, 4 mm, 5 mm wire diameter.
Stainless steel wire welded fencing panels for build a fence around organic garden. It is sturdy (chicken wire is too flimsy), anti-rust, and non-toxic to the soil and plants.
Stainless steel mesh 25 mm × 25 mm mesh for seagull defence, as barriers against seagulls nesting on roof and chimney.
Applications:
Stainless steel welded Grid Wall Panel with excellent corrosion resistance and oxidation resistance, is extensively used as fencing, decoration and machinery protection material in agriculture, construction, transport, mine, sports field, lawn and various industrial fields
