Type 316 stainless steel welded wire mesh panel with opening size12mm x 12mm,15mm x 15mm and rectangular hole 25mmx 25mm welded mesh panels,With Wire dia.1.6mm-6.00mm ss mesh panels. More sizes listed for export.
Hits:Print

Stainless steel welded mesh panels

Stainless steel welded mesh panels normal use Made from 304 grade stainless steel wire, For welded together to form a grid and comes prefabricated in sheets of different aperture sizes, and different gauges of wire. This products has excellent resistance to corrosion even when used in external applications; unlike mild steel, it does not need a protective coating or paint to protect it, therefore requires minimal maintenance.It is also known in a variety of other names, including wire mesh panel, grill mesh, weld mesh sheet, and welded wire mesh sheet.

Common stainless Steel Wire Raw Materials include:

Stainless Steel  Wire 304

Stainless Steel Wire  304L

Stainless Steel Wire  316

Stainless Steel Wire  316L

Characteristics:

Stainless Steel Welded Mesh Panels offer excellent characteristics such as corrosion resistance, oxidation resistance, acid resistance, alkali resistance, aging resistance, sunshine resistance and weather resistance. Besides this kind of product has flat even surface and strong structure, therefore this product has a long service life. Good material life of up to several decades.

Specification of  Stainless Steel Welded Mesh Panels

Item

Mesh Size

Wire Diameter

Panel Width & Length

SSWMPS-01

12.7 mm

1/2" × 1/2"

1.0–2.0 mm

3 feet × 6 feet
4 feet × 8 feet
5 feet × 10 feet
1 m × 2 m
1.5 m × 3 m
2 m × 4 m

SSWMPS-02

25.4 mm

1" × 1"

1.5–3.5 mm

SSWMPS-03

38.1 mm

1-1/2" × 1-1/2"

2.0–5.0 mm

SSWMPS-04

50.8 mm

2" × 2"

2.0–6.0 mm

SSWMPS-05

76.2 mm

3" × 3"

3.0–7.0 mm

SSWMPS-06

101.6 mm

4" × 4"

3.0–8.0 mm

SSWMPS-07

127 mm

5" × 5"

4.0–9.0 mm

SSWMPS-08

152.4 mm

6" × 6"

4.0–10.0 mm

other panel sizes can also be made according to request

The most popular products and specifications


4' × 8' panels in stainless steel with 4" opening and 4.0 mm wire diameter.

4" × 4" openings mesh panel. Ideally 3' × 16' or similar that can be cut down to size.

Stainless steel mesh 50 mm × 50 mm, wire diameter 4 mm.

304 stainless steel welded mesh panel with 2" × 2" mesh size that is 5 ft. by 10 ft.

Stainless steel panels, approx 72 × 60, 1/2 ' squares for building an aviary.

Stainless steel 4" × 4" wire panel. 4 or 6 gauge 10' long by 30" tall or 5' tall.

Stainless steel welded mesh panel (4 ft. × 8 ft. and 5 ft. × 10 ft.) from 16 or 14 gauge wire 1 × 1/2" for outdoor aviary.

51" × 43" × 1-1/2" sq. × 4 mm thick stainless steel weld mesh.

Stainless steel wire mesh black coated finish 12 mm × 12 mm square mesh.

Stainless steel wire mesh insect screen 4 mm × 4 mm square black coated.

304 Stainless steel and 316 Stainless steel 10' by 10' sections with 2" × 2" openings with the 2 mm diameter used in light weight application.

4 ft. long × 3 ft. wide of the 1/2" × 1/2" stainless steel 304 mesh piece, bordering these pieces with 2" × 2" ninety degree angle 304 stainless steel.

10 gauge and 8 gauge 2" × 2" stainless steel heavy duty welded mesh guarding bar for bridge building.

Stainless steel welded mesh panel, 1" × 1", 1-1/2" × 1-1/2", 2" × 2" mesh, 3 mm, 4 mm, 5 mm wire diameter.

Stainless steel wire welded fencing panels for build a fence around organic garden. It is sturdy (chicken wire is too flimsy), anti-rust, and non-toxic to the soil and plants.

Stainless steel mesh 25 mm × 25 mm mesh for seagull defence, as barriers against seagulls nesting on roof and chimney.

Applications:

Stainless steel welded mesh panels is primarily used for fencing, guards, enclosures, and security grill panels. It is also used by artists to create sculptures, by archaeologists to demarcate working areas, in gardening and
horticulture, and as screens and cages to protect birds and other animals from predators or escape. Such as Fireplace Screen Mesh, Cooking wire mesh,Foundation Vent Meshes, Gutter Guard Mesh, Cabinets Mesh,
Door Screen Mesh, a radiator stone guard on motorcycle, making a nice hamster cage, making a rustproof mesh on the intake air inlet, outdoor fire pit to line the weep holes, using on grill to cook bacon, earring holder etc.
The Stainless steel welded mesh sheet Having no cracks or pours to harbour dirt or bacteria, the smooth surface of stainless steel gives it excellent hygiene properties, so it is also often used in the food and catering industry,
as well as the health services. The mechanical resistance of stainless steel makes it durable to scratching and other damage, providing it with it aesthetically attractive appearance, and giving it low maintenance properties.
